- Innovative Design:
- No Electrolytic Capacitors
- Ultra-Long Lifetime
- Programmable, Enabling Hundreds of Configurations
- Controls-Ready:
- Always-ON Auxiliary Power: 12V, 200mA
- Dim-to-Off with Standby Power ≤ 0.5W
- Dimming Controls:
- 0-10V, PWM, Multiple Timers
- Input Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- Thermal Sensing and Protection for the LED Module
- SELV Output
- 10 Year Warranty
Life Time
100,000 hours @ Case Temperature 85°C
Dimensions
Inches (L x W x H)
8.86 x 2.66 x 1.56
Millimeters (L x W x H)
225 x 67.5 x 39.7
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 1050 mA |
90 ~ 305 Vac |
114 – 343 Vdc |
240 W |
EUD-240S105DVL |
| 1400 – 2100 mA | 1400 mA | 57 – 171 Vdc | EUD-240S210DVL | ||
| 2800 – 4200 mA | 4200 mA | 29 – 86 Vdc | EUD-240S420DVL | ||
| 4450 – 6700 mA | 6700 mA | 18 – 54 Vdc | EUD-240S670DVL |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
