• Low THD, 10% Max up to 240Vac
  • Input Surge Protection:
    • 4kV DM, 6kV CM
  • Compact Metal Housing
  • Input Over Voltage Protection (OVP)
  • Input Under Voltage Protection (UVP)
  • Suitable for Independent Use and Class I Luminaires
  • IP66
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

97,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.54 x 2.66 x 1.56

Millimeters (L x W x H)
166 x 67.5 x 39.7

Certifications

Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 mA

140 ~ 305 Vac
127 ~ 300 Vdc

 107 – 214 Vdc

150 W

 EDC-150S105ST-0007
860 mA 97 – 174 Vdc EDC-150S105ST-0004
1050 mA 97 – 143 Vdc EDC-150S105ST
