- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- DALI-2 and D4i Certified
- 3-Timer-Modes Dimmable
- Dim-to-Off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 24Vdc, 125mA, 3W (Transient Peak Power up to 10W)
- Integrated 16Vdc Current Source Power Supply Based on DALI-2
- Integrated Power Monitoring with High Accuracy up to ±1%
- Output Lumen Compensation
- End-of-Life Indicator
- Thermal Sensing and Protection for LED Module
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 7 Years Warranty
Life Time
112,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.82 × 3.15 × 1.75
Millimeters (L x W x H)
224 × 80 × 44.5
Certifications
| Adjustable Output Current Range(mA) | Full-Power Current
Range(mA) |
Default Output Current(mA) | Output Voltage Range(Vdc) | Max. Output Power(W) | Typical
Efficiency |
Typical
Power Factor |
Model Number | |
| 120Vac | 220Vac | |||||||
| 70-1050 | 700-1050 | 700 | 153-457 | 320 | 94.5% | 0.99 | 0.96 | EUM-320S105BB |
| 105-1500 | 1050-1500 | 1400 | 107-305 | 320 | 94.0% | 0.99 | 0.96 | EUM-320S150BB |
| 175-2500 | 1750-2500 | 2100 | 64-183 | 320 | 94.0% | 0.99 | 0.96 | EUM-320S250BB |
| 285-5000 | 2850-5000 | 4900 | 32-112 | 320 | 93.5% | 0.99 | 0.96 | EUM-320S500BB |
| 535-7600 | 5350-7600 | 6700 | 21-60 | 320 | 92.5% | 0.99 | 0.96 | EUM-320S760BB |
|
