- Ultra High Efficiency (Up to 96.5%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/PWM/3-Timer-Modes Dimmable
- Adjustable Dimming Curve
- INV Digital Dimming, UART Based Communication Protocol
- Dim-to-Off with Low Standby Power
- Minimum Dimming Level with 5% or 10% Selectable
- Hold Time Adjustable
- Fade Time Adjustable
- Always-on Auxiliary Power: 12Vdc, 250mA
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous
(Classified) Location - 5 Year Warranty
Life Time
101,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
11.22 x 5.55 x 1.90
Millimeters (L x W x H)
285 x 141 x 48.5
Certifications
| Adjustable Output Current Range(A) |
Full-Power Current Range(A) |
Default Output Current(A) |
Output Voltage Range(Vdc) |
Max. Output Power(W) |
Typical Efficiency |
Typical Power Factor |
Model Number | |
| 277Vac | 480Vac | |||||||
| 0.26-3.5 | 2.6-3.5 | 3.5 | 171-462 | 1200 | 96.5% | 0.99 | 0.96 | ESM-1K2S350MT |
| 0.395-5.25 | 3.95-5.25 | 5.25 | 114-304 | 1200 | 96.0% | 0.99 | 0.96 | ESM-1K2S525MT |
| 0.555-7.4 | 5.55-7.4 | 7.4 | 81-217 | 1200 | 96.5% | 0.99 | 0.96 | ESM-1K2S740MT |
|
