• Compact Metal Case with Excellent Thermal Performance
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with Programmability
  • Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP66/IP67 and UL Dry/Damp/Wet Location
  • SELV Output
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

110,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.82 x 3.15 x 1.75

Millimeters (L x W x H)
224 x 80 x 44.5

Certifications

Adjustable
Output
Current
Range (mA)		 Full-Power
Current
Range
(mA)		 Default
Output
Current
(mA)		 Output
Voltage
Range
(Vdc)		 Max.
Output
Power
(W)		 Typical
Efficiency		 Typical Power Factor Model Number
120Vac 220Vac
70-1050 700-1050 700 153-457 320 94.0% 0.99 0.96 EUM-320S105DT
105-1500 1050-1500 1400 107-305 320 94.0% 0.99 0.96 EUM-320S150DT
175-2500 1750-2500 2100 64-183 320 94.0% 0.99 0.96 EUM-320S250DT
285-5000 2850-5000 4900 32-112 320 93.0% 0.99 0.96 EUM-320S500DT
535-7600 5350-7600 6700 21-60 320 93.0% 0.99 0.96 EUM-320S760DT
