Not Recommended for New Design
We Recommend the EBS-080SxxxDT2 as a Replacement

  • Programmable Dimming Controls:
    • 0-10V, PWM, Multiple Timer
  • Controls-Ready:
    • Always-On Auxiliary Power 12Vdc/200mA
  • Dim-to-Off with Low Standby Power
  • High Level Surge Protection:
    • 6kV CM, 10kV DM
  • Thermal Sensing and Protection for LED module
  • Output Lumen Compensation
  • Suitable for Luminaires with Protection Class I and II
  • Built-in Use for Outdoor Applications
  • Independent Use for Indoor Applications with Optional Endcap
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

120,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
4.93 x 3.35 x 1.42

Millimeters (L x W x H)
125 x 85 x 36

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
450 – 700 mA 530 mA 176 ~ 305 Vac
190 ~ 250 Vdc		 57 – 178 Vdc 80 W EBS-080S070DTE
700 – 1050 mA 700 mA 38 – 114 Vdc EBS-080S105DTE
File Name
LED Driver Installation Guidelines (Updated September 2018)
Download
Programming Interface Device Driver Install First (Updated March 2015)
Download
Design-In Guide for Programmable Drivers (Updated September 2018)
Download
