Not Recommended for New Design
We Recommend the EBS-120SxxxBT2 as a Replacement
- Programmable
- Full Power at a Wide Range of Output Currents
- Dimming Controls:
- DALI, AC DIm, Multiple Timers
- Controls-Ready:
- Always-On Auxiliary Power 12Vdc/200mA
- Dim-to-Off with Low Standby Power
- High Level Surge Protection:
- 6kV DM, 10kV CM
- Thermal Sensing and Protection for LED module
- Output Lumen Compensation
- Suitable for Luminaires with Protection Class I and II
- Built-in Use for Outdoor Applications
- Independent Use for Indoor Applications with Optional Endcap
- 7 Year Warranty
Life Time
120,000 hours @ Case Temperature 75°C
Dimensions
Inches (L x W x H)
6.50 x 2.76 x 1.56
Millimeters (L x W x H)
165 x 70 x 39.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 500 – 700 mA | 530 mA |
176 ~ 305 Vac |
86 – 240 Vdc |
120 W |
EBS-120S070BTE |
| 700 – 1050 mA | 700 mA | 57 – 171 Vdc | EBS-120S105BTE | ||
| 1050 – 1500 mA | 1050 mA | 40 – 114 Vdc | EBS-120S150BTE |
|
