• Input Surge Protection:
    • 4kV DM, 6kV CM
  • Compact Metal Housing
  • Input Over Voltage Protection (OVP)
  • Input Under Voltage Protection (UVP)
  • Suitable for Independent Use and Class I Luminaires
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

96,000 hours @ Case Temperature 60°C

Dimensions

Inches (L x W x H)
5.7x 2.7x 1.4

Millimeters (L x W x H)
145x 67.5x 36.5

Certifications

Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 mA

140 ~ 305 Vac

 71 – 143 Vdc

100 W

 EDC-100S105SV-0007
860 mA 58 – 116 Vdc EDC-100S105SV-0004
1050 mA 47 – 95 Vdc EDC-100S105SV

Notes:
(1) Certified input voltage range: 220-240Vac.
(2) Operating input voltage range: 100-305Vac, and 100-140Vac is for safety operation.
(3) Measured at 100% load and 220Vac input.
(4) Certified to BIS.
(5) For BIS models please click here see the: BIS Models List
