• Input Over Voltage Protection at 440Vac with 48 Hours
  • Low THD, 10% Max up to 240 Vac
  • High Efficiency (Up to 92.5%)
  • Input Surge Protection: DM 4kV, CM 6kV
  • High Reliability & Long Lifetime: 120,000 Hrs. at 70°C Case Temperature
  • Suitable for Class I Luminaires
  • IUVP & IOVP
  • IP66/IP67
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

97,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.54 x 2.36 x 1.44

Millimeters (L x W x H)
166 x 60 x 36.5

Certifications

Output Current Range (mA) Output Voltage Range (Vdc) Max. Output Power (W) Typical Efficiency Power Factor Model Number
700 107-214 150 92.0% 0.96 EDC-150S105SV-0007
860 97-174 150 92.5% 0.96 EDC-150S105SV-0004
1050 97-143 150 91.5% 0.96 EDC-150S105SV

Notes:
(1) Certified input voltage range: 220-240Vac.
(2) Operating input voltage range: 100-305Vac, and 100-140Vac is for safety operation.
(3) Measured at 100% load and 220Vac input.
(4) Certified to BIS.
(5) For BIS models please click here see the: BIS Models List
