• Ultra High Efficiency (Up to 95%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • Isolated 0-10V/PWM/3-Timer-Modes Dimmable
  • Dim-to-Off with Standby Power ≤ 1.5W
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

102,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
9.25 x 4.92 x 1.71

Millimeters (L x W x H)
235 x 125 x 43.5

Certifications

Independent Gear Logo

Adjustable
Output
Current
Range		 Full-Power
Current
Range		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
277Vac 480Vac
0.105-1.40A 1.05A-1.40A 1.4 A 249~528Vac
352~500Vdc		 171 ~ 457Vdc 480 W 95.0% 0.96 0.95 ESD-480S140DV
0.210-2.80A 2.10-2.80A 2.8 A 249~528Vac
352~500Vdc		 86 ~ 228Vdc 480 W 94.5% 0.96 0.95 ESD-480S280DV
0.315-4.20A 3.15-4.20A 4.2 A 249~528Vac
352~500Vdc		 57 ~ 152Vdc 480 W 94.0% 0.96 0.95 ESD-480S420DV
0.435-5.60A 4.35-5.60A 5.6 A 249~528Vac
352~500Vdc		 43 ~ 110Vdc 480 W 93.5% 0.96 0.95 ESD-480S560DV
0.750-10.0A 7.50-10.0A 10.0 A 249~528Vac
352~500Vdc		 24 ~ 64Vdc 480 W 93.5% 0.96 0.95 ESD-480S10ADV
File Name
LED Driver Installation Instructions (Updated 3-3-2015)
Download
Programming Interface Device Driver Install First (Updated 3-3-2015)
Download
Design-In Guide for Programmable Drivers (Updated September 2018)
Download
Programming Interface Installation Instructions (Updated 4-22-2015)
Download
Programming Interface Operating Instructions (Updated 1-13-2016)
Download
Inventronics Constant Power Programmer Manual Instruction (Updated 2018)
Download
