The EUC-036SxxxDV(SV) models are not recommended for new design. They have limited availability and will be sold while supplies last. We recommend the EUM-030SxxxDG or the EUM-050SxxxDG as a replacement.

  • High Efficiency (Up to 89%)
  • Second Generation with Improved Performance
  • Active Power Factor Correction (Typical 0.95)
  • Constant Current Output
  • 0-10V Dimmable
  • Input Surge Protection: DM 4kV, CM 6kV
  • All-Around Protection: OVP, SCP, OLP, OTP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

117,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.77 x 1.77 x 1.38

Millimeters (L x W x H)
172 x 42 x 35

Certifications

Independent Gear Logo

Output Current Input Voltage
Range		 Output Voltage Range Max. Output Power Typical Efficiency Typical Power Factor Model Number
120Vac 220Vac
350 mA 90 ~ 305 Vac 52~103 Vdc 36 W 89% 0.96 0.95 EUC-036S035DV(SV)
450 mA 90 ~ 305 Vac 40~80 Vdc 36 W 88% 0.96 0.95 EUC-036S045DV(SV)
700 mA 90 ~ 305 Vac 26~52 Vdc 36 W 88% 0.96 0.95 EUC-036S070DV(SV)
1050 mA 90 ~ 305 Vac 18~35 Vdc 36 W 87% 0.96 0.95 EUC-036S105DV(SV)
1400 mA 90 ~ 305 Vac 13~26 Vdc 36 W 86% 0.96 0.95 EUC-036S140DV(SV)
1750 mA 90 ~ 305 Vac 11~21 Vdc 36 W 85% 0.96 0.95 EUC-036S175DV(SV)
