- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 1(0)-5V/1(0)-10V/10V PWM/3-Timer-Modes
- Adjustable Dimming Curve
- High Reliability & Long Lifetime: 119,000 hrs. at 70°C Case Temperature
- Dim-to-Low-Voltage with Standby Power ≤ 0.5W
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OVP, SCP, OTP
- IP66 and UL Dry/Damp Location
- SELV Output
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- Suitable for Class I Luminaires
- 5 Year Warranty
Life Time
119,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
3.74 x 2.52 x 1.26
Millimeters (L x W x H)
95 x 64 x 32
Certifications
| Adjustable Output Current Range (mA) |
Full-Power Current Range (mA) |
Default Output Current (mA) |
Output Voltage Range (Vdc) |
Max. Output Power (W) |
Typical Efficiency |
Typical Power Factor | Model Number | |
| 120Vac | 220Vac | |||||||
|
50-700 |
500-700 |
700 |
40-80 |
40 |
88.5% |
0.99 |
0.96 |
EUC-040S070Hx |
|
70-1050 |
700-1050 |
1050 |
28-57 |
40 |
87.5% |
0.99 |
0.96 |
EUC-040S105Hx |
|
