The EUC-052SxxxSV model is not recommended for new design. It has limited availability and will be sold while supplies last. We recommend the EUM-050SxxxSG as a replacement.
- High Efficiency (Up to 90%)
- Second Generation with Improved Performance
- Active Power Factor Correction (Typical 0.95)
- Constant Current Output
- 0-10V Dimmable
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OVP, SCP, OLP, OTP
- IP67
- SELV Output
- 5 Year Warranty
Life Time
93,300 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.77 x 1.77 x 1.38
Millimeters (L x W x H)
172 x 45 x 35
Certifications
Output Current | Input Voltage Range |
Output Voltage Range | Max. Output Power | Typical Efficiency | Typical Power Factor | Model Number | |
---|---|---|---|---|---|---|---|
120Vac | 220Vac | ||||||
350 mA | 90 ~ 305 Vac | 75~149 Vdc | 52 W | 90% | 0.96 | 0.95 | EUC-052S035DV(SV) |
450 mA | 90 ~ 305 Vac | 58~116 Vdc | 52 W | 89% | 0.96 | 0.95 | EUC-052S045DV(SV) |
700 mA | 90 ~ 305 Vac | 38~75 Vdc | 52 W | 89% | 0.96 | 0.95 | EUC-052S070DV(SV) |
1050 mA | 90 ~ 305 Vac | 25~50 Vdc | 52 W | 88% | 0.96 | 0.95 | EUC-052S105DV(SV) |
1400 mA | 90 ~ 305 Vac | 19~37 Vdc | 52 W | 87% | 0.96 | 0.95 | EUC-052S140DV(SV) |
2100 mA | 90 ~ 305 Vac | 13~25 Vdc | 52 W | 86% | 0.96 | 0.95 | EUC-052S210DV(SV) |
File Name
|
---|
LED Driver Installation Instructions (Updated March 2015)
|
LED Driver Installation Guidelines (Updated September 2018)
|
