- Four Channel Outputs
- Dimming Controls:
- DV: 0-10V
- SV: Non-Dimming
- Input Surge Protection:
- 4kV DM, 6kV CM
- SELV Output
- 5 Year Warranty
Life Time
94,800 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
7.40 x 3.46 1.50
Millimeters (L x W x H)
188 x 88 x 38
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA |
90 ~ 305 Vac |
57 – 103 Vdc | 144 W | EUC-160Q035DV(SV) |
| 450 mA | 45 – 90 Vdc | 160 W | EUC-160Q045DV(SV) | |
| 600 mA | 40 – 70 Vdc | 168 W | EUC-160Q060DV(SV) | |
| 700 mA | 29 – 57 Vdc |
160 W |
EUC-160Q070DV(SV) | |
| 1050 mA | 19 – 38 Vdc | EUC-160Q105DV(SV) | ||
| 1400 mA | 14 – 29 Vdc | EUC-160Q140DV(SV) |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guidelines (Updated September 2018)
|
