This Series is Not Recommended for New Design

We Recommend our EUM-075SxxxDG as a Replacement

  • High Efficiency (Up to 91%)
  • Full Power at Wide Output Current Range (Constant Power)
  • 0-10V/PWM/3-Timer-Modes Dimmable
  • Dim-to-Off with Standby Power ≤ 0.5W
  • Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak Current up to 400mA)
  • Thermal Sensing and Protection for LED Module
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

98,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.10 x 2.66 x 1.44

Millimeters (L x W x H)
155 x 67.5 x 36.5

Certifications

Independent Gear Logo

Adjustable
Output
Current
Range		 Full-Power
Current
Range		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
120Vac 220Vac
45-700mA 450-700mA 530 mA 90~305 Vac/
127~250 Vdc		 54~167Vdc 75 W 91.0% 0.99 0.96 EUD-075S070DV
70-1050mA 700-1050mA 700 mA 90~305 Vac/
127~250 Vdc		 36~107Vdc 75 W 91.0% 0.99 0.96 EUD-075S105DV
119-1750mA 1190-1750mA 1400 mA 90~305 Vac/
127~250 Vdc		 22 ~ 63Vdc 75 W 90.5% 0.99 0.96 EUD-075S175DV
192-2800mA 1920-2800mA 2100 mA 90~305 Vac/
127~250 Vdc		 14 ~ 39Vdc 75 W 89.5% 0.99 0.96 EUD-075S280DV
