- Innovative Design:
- No Electrolytic Capacitors
- Ultra-Long Lifetime
- Programmable, Enabling Hundreds of Configurations
- Controls-Ready:
- Always-ON Auxiliary Power: 12V, 200mA
- Dim-to-Off with Standby Power ≤ 0.5W
- Dimming Controls:
- 0-10V, PWM, Multiple Timers
- Input Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- Thermal Sensing and Protection for the LED Module
- SELV Output
- 10 Year Warranty
Life Time
100,000 hours @ Case Temperature 85°C
Dimensions
Inches (L x W x H)
7.09 x 2.66 x 1.44
Millimeters (L x W x H)
180 x 67.5 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 530 mA |
90 ~ 305 Vac |
74 – 213 Vdc |
96 W |
EUD-096S070DVL |
| 700 – 1050 mA | 700 mA | 48 – 137 Vdc | EUD-096S105DVL | ||
| 1400 – 2100 mA | 2100 mA | 24 – 69 Vdc | EUD-096S210DVL | ||
| 2450 – 3500 mA | 2800 mA | 14 – 39 Vdc | EUD-096S350DVL |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
