- Ultra High Efficiency (Up to 94%)
- Full Power at Wide Output Current Range (Constant Power)
- Thermal Sensing and Protection for LED Module
- 0-10V/PWM/3-Timer-Modes Dimmable (DVA models)
DALI Dimming Control (BVA models) - Dim-to-Off with Standby Power ≤ 0.5W
- Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak
Current up to 400mA) - Output Lumen Compensation (DVA models)
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67
- SELV Output
- 7 Year Warranty
Life Time
100,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.03 x 2.66 x 1.56
Millimeters (L x W x H)
204 x 67.5 x 39.7
Certifications
| Adjustable Output Current Range |
Full-Power Current Range |
Default Output Current |
Input Voltage Range |
Output Voltage Range |
Max. Output Power |
Typical Efficiency |
Typical Power Factor |
Model Number | |
| 120Vac | 220Vac | ||||||||
| 70-1050mA | 700-1050mA | 700 mA | 90~305Vac 100~250Vdc |
75~214Vdc | 150 W | 94.0% | 0.99 | 0.96 | EUD-150S105BVA |
| 140-2100mA | 1400-2100mA | 1400 mA | 90~305Vac 100~250Vdc |
38~107Vdc | 150 W | 94.0% | 0.99 | 0.96 | EUD-150S210BVA |
| 245-3500mA | 2450-3500mA | 3150 mA | 90~305Vac 100~250Vdc |
22 ~ 61Vdc | 150 W | 93.5% | 0.99 | 0.96 | EUD-150S350BVA |
| 385-5600mA | 3850-5600mA | 4200 mA | 90~305Vac 100~250Vdc |
14 ~ 39Vdc | 150 W | 93.5% | 0.99 | 0.96 | EUD-150S560BVA |
|
