• Ultra High Efficiency (Up to 94%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • 0-10V/PWM/3-Timer-Modes Dimmable (DVA models)
  • DALI Dimming Control (BVA models)
  • Dim-to-Off with Standby Power ≤ 0.5W
  • Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak
    Current up to 400mA)
  • Output Lumen Compensation (DVA models)
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

100,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.03 x 2.66 x 1.56

Millimeters (L x W x H)
204 x 67.5 x 39.7

Certifications

Here’s the data formatted into a table:

Adjustable Output Current Range Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Typical Efficiency Typical Power Factor Model Number
70-1050mA 700-1050mA 700 mA 90~305Vac
100~250Vdc		 75~214Vdc 150 W 94.0% 0.99 (120Vac) / 0.96 (220Vac) EUD-150S105DVA(BVA)
140-2100mA 1400-2100mA 1400 mA 90~305Vac
100~250Vdc		 38~107Vdc 150 W 94.0% 0.99 (120Vac) / 0.96 (220Vac) EUD-150S210DVA(BVA)
245-3500mA 2450-3500mA 3150 mA 90~305Vac
100~250Vdc		 22~61Vdc 150 W 93.5% 0.99 (120Vac) / 0.96 (220Vac) EUD-150S350DVA(BVA)
385-5600mA 3850-5600mA 4200 mA 90~305Vac
100~250Vdc		 14~39Vdc 150 W 92.5% 0.99 (120Vac) / 0.96 (220Vac) EUD-150S560DVA(BVA)
