• Ultra High Efficiency (Up to 94.5%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • 0-10V/PWM/3-Timer-Modes Dimmable
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak
    Current up to 400mA)
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

108,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.27 x 2.66 x 1.56

Millimeters (L x W x H)
210 x 67.5 x 39.5

Certifications

Adjustable
Output
Current
Range		 Full-Power
Current
Range		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
120Vac 220Vac
70-1050mA 700-1050mA 700 mA 90~305Vac
100~250Vdc		 95~286Vdc 200 W 94.5% 0.99 0.96 EUD-200S105DVA
140-2100mA 1400-2100mA 1400 mA 90~305Vac
100~250Vdc		 48~143Vdc 200 W 94.0% 0.99 0.96 EUD-200S210DVA
245-3500mA 2450-3500mA 2800 mA 90~305Vac
100~250Vdc		 29 ~ 82Vdc 200 W 93.5% 0.99 0.96 EUD-200S350DVA
385-5600mA 3850-5600mA 4900 mA 90~305Vac
100~250Vdc		 18 ~ 52Vdc 200 W 93.0% 0.99 0.96 EUD-200S560DVA
