• Ultra High Efficiency (Up to 94%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • DALI/Timer Dimmable (3 Timer Modes)
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Always-on Auxiliary Power: 12Vdc, 200mA (Transient Peak Current up to 400mA)
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

96,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.63 x 2.66 x 1.56

Millimeters (L x W x H)
219 x 67.5 x 39.7

Certifications

Independent Gear Logo

Adjustable
Output
Current
Range		 Full-Power
Current
Range		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
120Vac 220Vac
70-1050mA 700-1050mA 1050 mA 90~305 Vac
127~250 Vdc		 114~343Vdc 240 W 94.0% 0.99 0.96 EUD-240S105BVA
105-1500mA 1050-1500mA 1050 mA 90~305 Vac
127~250 Vdc		 80~229Vdc 240 W 93.0% 0.99 0.96 EUD-240S150BVA
140-2100mA 1400-2100mA 1400 mA 90~305 Vac
127~250 Vdc		 57~171Vdc 240 W 93.5% 0.99 0.96 EUD-240S210BVA
280-4200mA 2800-4200mA 4200 mA 90~305 Vac
127~250 Vdc		 29 ~ 86Vdc 240 W 93.0% 0.99 0.96 EUD-240S420BVA
445-6700mA 4450-6700mA 6700 mA 90~305 Vac
127~250 Vdc		 18 ~ 54Vdc 240 W 93.0% 0.99 0.96 EUD-240S670BVA
