• Programmable, Enabling Hundreds of Configurations
  • Controls-Ready:
    • Always-On Auxiliary Power: 12V, 200mA
    • Dim-to-Off with Low Standby Power
  • Dimming Controls:
    • DALI, Multiple Timers
  • High Level of Built-in Surge Protection:
    • 6kV DM, 10kV CM
  • Output Lumen Compensation
  • Thermal Sensing and Protection for LED ModuleSELV Output
  • IP67 and UL Dry/Damp/Wet Location
  • Suitable for Independent Use
  • 7 Year Warranty

Life Time

97,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.86 x 3.86 x 1.77

Millimeters (L x W x H)
225 x 98 x 44.8

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
1050 – 1500 mA 1400 mA

90 ~ 305 Vac
127 ~ 300 Vdc

107 – 305 Vdc

320 W

EUD-320S150BT
1540 – 2200 mA 2100 mA 73 – 208 Vdc EUD-320S220BT
2240 – 3200 mA 2800 mA 50 – 143 Vdc EUD-320S320BT
3220 – 4600 mA 4200 mA 35 – 100 Vdc EUD-320S460BT
4690 – 6700 mA 6700 mA 24 – 68 Vdc EUD-320S670BT
