• Ultra High Efficiency (Up to 94%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • 0-10V/PWM/3-Timer-Modes Dimmable
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Always-on Auxiliary Power: 12Vdc, 200mA
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67 and UL Dry/Damp/Wet Location
  • SELV Output
  • TYPE HL, for Use in a Class I, Division 2 Hazardous
    (Classified) Location
  • 7 Year Warranty

Life Time

97,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.82 x 3.86 x 1.75

Millimeters (L x W x H)
224 x 98 x 44.8

Certifications

Adjustable
Output
Current
Range
Full-Power Current Range (mA) Default Output Current (mA) Input Voltage Range (Vac/Vdc) Output
Voltage
Range (Vdc)
Max. Output Power (W) Typical Efficiency Typical Power Factor Model Number
120Vac 220Vac
105-1500 1050-1500 1400 90~305Vac/ 127~300Vdc 107~305 320 94.0% 0.99 0.96 EUD-320S150DT
154-2200 1540-2200 2100 90~305Vac/ 127~300Vdc 73~208 320 93.5% 0.99 0.96 EUD-320S220DT
224-3200 2240-3200 2800 90~305Vac/ 127~300Vdc 50~143 320 93.5% 0.99 0.96 EUD-320S320DT
322-4600 3220-4600 4200 90~305Vac/
127~300Vdc
35~100 320 93.5% 0.99 0.96 EUD-320S460DT
469-6700 4690-6700 6700 90~305 Vac/
127~300Vdc
24 ~ 68 320 93.5% 0.99 0.96 EUD-320S670DT
