• Ultra High Efficiency (Up to 94%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Thermal Sensing and Protection for LED Module
  • 0-10V/PWM/3-Timer-Modes Dimmable
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Always-on Auxiliary Power: 12Vdc, 200mA
  • Output Lumen Compensation
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty

Life Time

97,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.86 x 3.86 x 1.75

Millimeters (L x W x H)
225 x 98 x 44.8

Certifications

Adjustable
Output
Current
Range
Full-Power
Current
Range
Default
Output
Current
Input
Voltage
Range
Output
Voltage
Range
Max.
Output
Power
Typical
Efficiency
Typical
Power Factor
Model Number
120Vac 220Vac
105-1500mA 1050-1500mA 1400 mA 90~305 Vac
127~250 Vdc
107~305Vdc 320 W 94.0% 0.99 0.96 EUD-320S150DV
154-2200mA 1540-2200mA 2100 mA 90~305 Vac
127~250 Vdc
73~208Vdc 320 W 93.5% 0.99 0.96 EUD-320S220DV
224-3200mA 2240-3200mA 2800 mA 90~305 Vac
127~250 Vdc
50~143Vdc 320 W 93.5% 0.99 0.96 EUD-320S320DV
322-4600mA 3220-4600mA 4200 mA 90~305 Vac
127~250 Vdc
35~100Vdc 320 W 93.5% 0.99 0.96 EUD-320S460DV
469-6700mA 4690-6700mA 6700 mA 90~305 Vac/
127~250 Vdc
24 ~ 68Vdc 320 W 93.5% 0.99 0.96 EUD-320S670DV
