• Ultra High Efficiency (Up to 93%)
  • Full Power at Wide Output Current Range (Constant Power)
  • 0-5V/0-10V/PWM/Timer Dimmable
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

98,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.85 x 2.66 x 1.44

Millimeters (L x W x H)
174 x 67.5 x 36.5

Certifications

Independent Gear Logo

Adjustable
Output
Current
Range		 Full-Power
Current
Range 		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
120Vac 220Vac
45-700mA 450-700mA 530 mA 90 ~ 305 Vac
100 ~ 250 Vdc		 74~213Vdc 96 W 92.0% 0.99 0.96 EUG-096S070DV
70-1050mA 700-1050mA 700 mA 90 ~ 305 Vac
100 ~ 250 Vdc		 48~137Vdc 96 W 93.0% 0.99 0.96 EUG-096S105DV
140-2100mA 1400-2100mA 2100 mA 90 ~ 305 Vac
100 ~ 250 Vdc		 24 ~ 69Vdc 96 W 92.0% 0.99 0.96 EUG-096S210DV
245-3500mA 2450-3500mA 2800 mA 90 ~ 305 Vac
100 ~ 250 Vdc		 14 ~ 39Vdc 96 W 91.0% 0.99 0.96 EUG-096S350DV
