• Ultra High Efficiency (Up to 93.5%)
  • Full Power at Wide Output Current Range (Constant Power)
  • 0-5V/0-10V/PWM/Timer Dimmable
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: OVP, SCP, OTP
  • IP67
  • SELV Output
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

99,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
7.40 x 2.66 x 1.56

Millimeters (L x W x H)
188 x 67.5 x 39.7

Certifications

Adjustable
Output
Current
Range		 Full-Power
Current
Range		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
120Vac 220Vac
45-700mA 450-700mA 530 mA 90~305 Vac/
100~250 Vdc		 117~333Vdc 150 W 93.5% 0.99 0.96 EUG-150S070DV
70-1050mA 700-1050mA 700 mA 90~305 Vac/
100~250 Vdc		 75~214Vdc 150 W 93.5% 0.99 0.96 EUG-150S105DV
140-2100mA 1400-2100mA 1400 mA 90~305 Vac/
100~250 Vdc		 38~107Vdc 150 W 92.5% 0.99 0.96 EUG-150S210DV
245-3500mA 2450-3500mA 3150 mA 90~305 Vac/
100~250 Vdc		 22 ~ 61Vdc 150 W 92.0% 0.99 0.96 EUG-150S350DV
385-5600mA 3850-5600mA 4200 mA 90~305 Vac/
100~250 Vdc		 14 ~ 39Vdc 150 W 92.0% 0.99 0.96 EUG-150S560DV
