This product has been discontinued.
We recommend EUM-075sxxxDG as a replacement product.
- Programmable, Enabling Hundreds of Configurations
- Dimming Controls:
- DV: Isolated, 0-10V, 10V PWM
- TV: Multiple Timers
- Input Surge Protection:
- 6kV DM, 10kV CM
- SELV Output
- Suitable for Independent Use
- 5 Year Warranty
Life Time
84,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
5.71 x 2.66 x 1.44
Millimeters (L x W x H)
145 x 67.5 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 530 mA | 90 ~ 305 Vac 127 ~ 250 Vdc |
54 – 167 Vdc | 75 W | EUK-075S070DV(TV) |
| 700 – 1050 mA | 700 mA | 36 – 107 Vdc | EUK-075S105DV(TV) | ||
| 1190 – 1750 mA | 1400 mA | 22 – 63 Vdc | EUK-075S175DV(TV) | ||
| 1920 – 2800 mA | 2100 mA | 14 – 39 Vdc | EUK-075S280DV(TV) |
|
