- Programmable, Without the need of Powering on the Driver
- Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
- Built-in Surge Protection:
- 4kV DM, 6kV CM
- Output Lumen Compensation
- Suitable for Luminaires with Protection Class I
- Class 2 Models Available
- SELV Output Models Available
- Type HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- IP66 and IP67 Rated with UL Dry, Damp, Wet Location
- EUM-030SxxxDG Models: Global Cable to Reduce Inventory SKUs
- EUM-030SxxxDB Models: BIS Certified
- 5 Year Warranty
Life Time
120,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
3.75 x 2.52 x 1.44
Millimeters (L x W x H)
95 x 64 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 300 – 500 mA | 350 mA | 90 ~ 305 Vac 127 – 300 Vdc |
30 – 100 Vdc | 30 W | EUM-030S050DG |
| 550 – 1050 mA | 700 mA | 17 – 54 Vdc | EUM-030S105DG | ||
| Note: To order BIS approved models, please use suffix “DB” in place of “DG” (Ex: EUM-030S105DB) | |||||
|
