- Full-Power at a Wide Output Current Range
- Isolated Dimming Controls:
- 0-10V, PWM, Multiple Timers
- Controls-Ready
- Always-On Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
- Dim-to-Off
- High Level of Built-in Protection:
- 6kV DM, 10kV CM
- Input Over Voltage (IOVP) and Input Under Voltage (IUVP) Protection
- Inventronics Proprietary Digital Dimming Health Monitoring
- UART Based Communication Protocol
- Optimized, More Compact Form Factor
- End-of-Life Indicator
- Output Lumen Compensation
- Class 2 and SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- UL Class P
- TYPE HL, for use in a Class I, Division 2 Hazardous
- 5 Year Warranty
Life Time
101,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
4.92 x 2.66 x 1.44
Millimeters (L x W x H)
125 x 67.5 x 36.5
Certifications
| Adjustable Output Current Range (mA) | Full-Power Current Range (mA)(1) | Default Output Current (mA) | Output Voltage Range (Vdc) | Max. Output Power (W) | Typical Efficiency(2) | Typical Power Factor | Model Number(3)(6)(7) |
|---|---|---|---|---|---|---|---|
| 70-1050 | 700-1050 | 700 | 36-107 | 75 | 90.5% | 0.99 | EUM-075S105MT |
| 105-1500 | 1050-1500 | 1050 | 25-72 | 75 | 89.5% | 0.99 | EUM-075S150MT |
| 140-2100 | 1400-2100 | 2100 | 18-54 | 75 | 89.0% | 0.99 | EUM-075S210MT |
|
