- Programmable, Without the need of Powering on the Driver
-
- Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
- Built-in Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- All-Around Protection: OVP, SCP, OTP
- Suitable for Luminaires with Protection Class I and II
- SELV Output Models Available
- IP66 and IP67 Rated
- 5 Year Warranty
Life Time
114,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
5.35 x 2.36 x 1.44
Millimeters (L x W x H)
136 x 60 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 350 – 530 mA | 530 mA | 90 ~ 305 Vac 127 – 300 Vdc |
94 – 286 Vdc | 100 W | EUM-100S053DE |
| 700 – 1050 mA | 700 mA | 48 – 143 Vdc | EUM-100S105DE | ||
| 1050 -1500 mA | 1050 mA | 34 – 95 Vdc | EUM-100S150DE | ||
| 1750 – 2800 mA | 2100 mA | 17 – 54 Vcd | EUM-100S280DE |
|
