- Compact Metal Case with Excellent Thermal Performance
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
- Output Lumen Compensation
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- Class 2 & SELV Output
- TYPE HL, for Use in a Class I, Division 2 Hazardous
(Classified) Location - 5 Year Warranty
Life Time
114,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
5.16 x 2.36 x 1.44
Millimeters (L x W x H)
131 x 60 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 350 – 530 mA | 530 mA | 90 ~ 305 Vac 127 – 300 Vdc |
94 – 286 Vdc | 100 W | EUM-100S053DG |
| 700 – 1050 mA | 700 mA | 48 – 143 Vdc | 100 W | EUM-100S105DG | |
| 1050 – 1500 mA | 1050 mA | 34 – 95 Vdc | 100W | EUM-100S150DG | |
| 1750 – 2800 mA | 2100 mA | 17 – 54 Vdc | 96W | EUM-100S280DG | |
| Note: To order BIS approved models, please use suffix “DB” in place of “DG” (Ex: EUM-100S105DB) | |||||
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-in Guide for Programming Drivers (updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
