- Full-Power at a Wide Output Current Range
- Isolated Dimming Controls:
- 0-10V, PWM, Multiple Timers
- Controls-Ready
- Always-On Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
- Dim-to-Off
- Inventronics Proprietary Digital Dimming Health Monitoring
- UART Based Communication Protocol
- Global Cable Design to Reduce SKUs (with UL)
- Optimized, More Compact Form Factor
- High Level of Built-in Surge Protection:
- 6kV DM, 10kV CM
- End-of-Life Indicator
- Simplified Design for Easier Hi-Pot Testing
- Output Lumen Compensation
- SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
- 5 Year Warranty
Life Time
102,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.73 x 2.66 x 1.44
Millimeters (L x W x H)
171 x 67.5 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 530 – 700 mA | 530 mA | 90 ~ 305 Vac 127 – 300 Vdc |
142 – 378 Vdc | 200 W | EUM-200S070DG |
| 700 – 1050 mA | 700 mA | 95 – 286 Vdc | EUM-200S105MG | ||
| 1050 – 1500 mA | 1050 mA | 67 – 190 Vdc | EUM-200S150MG | ||
| 1800 – 2800 mA | 2100 mA | 36 – 111 Vdc | EUM-200S280MG | ||
| 3500 – 5600 mA | 4200 mA | 18 – 57 Vdc | EUM-200S560MG |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated December 2020)
|
