• DALI-2 D4i Certified
    • Offers Intra-Luminaire Solutions and Health Monitoring
    • Integrated 16Vdc Bus Power Supply based on DALI-2
  • Wireless Programming via Near Field Communication (NFC)
    • Compatible with Zhaga Book 24 Programmers
  • Integrated AC Power Monitoring with High Accuracy up to ±1%
  •  Controls-Ready
    • Always-On Auxiliary Power: 24Vdc, 125mA, 3W (Transient Peak Power up to 10W)
    • Dim-to-Off
  • Isolated Dimming Controls:
    • Multiple Timers
  • Optimized, More Compact Form Factor
  • High Level of Built-in Surge Protection:
    • 6kV DM, 10kV CM
  • End-of-Life Indicator
  • Thermal Sensing and Protection for LED Module
  • Simplified Design for Easier Hi-Pot Testing
  • Output Lumen Compensation
  • SELV Output Models Available
  • Input Under Voltage (IUV) and Input Over Voltage IIOV) Protection
  • IP66 and IP67 and UL Dry, Damp, Wet Location
  • UL Class P
  • TYPE HL, for use in a Class I, Division 2 Hazardous
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

112,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.82 x 3.15 x 1.75

Millimeters (L x W x H)
224 x 80 x 44.5

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 – 1050 mA 700 mA 90 ~ 305 Vac
127 – 300 Vdc		 153 – 457 Vdc 320 W EUM-320S105BT
1050 – 1500 mA 1400 mA 107 – 305 Vdc EUM-320S150BT
1750 – 2500 mA 2100 mA 64 – 183 Vdc EUM-320S250BT
2850 – 5000 mA 4900 mA 32 – 112 Vdc EUM-320S500BT
5350 – 7600 mA 6700 mA 21 – 60 Vdc EUM-320S760BT
