- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/PWM/3-Timer-Modes Dimmable
- INV Digital Dimming, UART Based Communication Protocol
- Dim-to-Off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- Global Cable Design to Reduce SKUs (with UL)
- Optimized, More Compact Form Factor
- End-of-Life Indicator
- Output Lumen Compensation
- SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
- 5 Year Warranty
Life Time
112,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.82 x 3.15 x 1.75
Millimeters (L x W x H)
224 x 80 x 44.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA | 90 ~ 305 Vac 127 – 300 Vdc |
153 – 457 Vdc | 320 W | EUM-320S105MT |
| 1050 – 1500 mA | 1400 mA | 107 – 305 Vdc | EUM-320S150MT | ||
| 1750 – 2500 mA | 2100 mA | 64 – 183 Vdc | EUM-320S250MT | ||
| 2850 – 5000 mA | 4900 mA | 32 – 112 Vdc | EUM-320S500MT | ||
| 5350 – 7600 mA | 6700 mA | 21 – 60 Vdc | EUM-320S760MT |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
