- Hot-plugging Protection
- Parallel LED Protection
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/PWM/Resistor Dimmable/3-Timer-Modes Dimmable
- Adjustable Dimming Curve
- INV Digital Dimming, UART Based Communication Protocol
- Dim-to-Off with Standby Power ≤ 0.5W
- Minimum Dimming Level with 5% or 10% Selectable
- Hold Time Adjustable
- Fade Time Adjustable
- Always-on Auxiliary Power: 12Vdc, 250mA
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Years Warranty
Life Time
102,000 Hours @220Vac input, 80%Load and 70°C case temperature.
Dimensions
Inches (L x W x H)
9.57 × 3.54 × 1.71
Millimeters (L x W x H)
243 × 90 × 43.5
Certifications
| Adjustable Output Current Range(A) |
Full-Power Current Range(A) |
Default Output Current(A) | Output Voltage Range(Vdc) |
Max. Output Power(W) |
Typical Efficiency | Typical Power Factor |
Model Number |
|
| 120Vac | 220Vac | |||||||
| 0.105-1.4 | 1.05-1.4 | 1.4 | 171-457 | 480 | 94.5% | 0.99 | 0.96 | EUM-480S140Mx |
| 0.21-2.8 | 2.1-2.8 | 2.8 | 86-228 | 480 | 94.0% | 0.99 | 0.96 | EUM-480S280Mx |
| 0.315-4.2 | 3.15-4.2 | 4.2 | 57-152 | 480 | 94.0% | 0.99 | 0.96 | EUM-480S420Mx |
| 0.435-5.6 | 4.35-5.6 | 5.6 | 43-110 | 480 | 94.0% | 0.99 | 0.96 | EUM-480S560Mx |
| 0.86-10 | 8.6-10 | 10 | 24-56 | 480 | 94.0% | 0.99 | 0.96 | EUM-480S10AMx |
