- Ultra High Efficiency (Up to 96%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/PWM/3-Timer-Modes Dimmable
- Adjustable Dimming Curve
- INV Digital Dimming, UART Based Communication Protocol
- Dim-to-Off with Standby Power ≤ 0.5W
- Minimum Dimming Level with 5% or 10% Selectable
- Hold Time Adjustable
- Fade Time Adjustable
- Always-on Auxiliary Power: 12Vdc, 250mA
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
107,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
9.84 x 5.31 x 1.81
Millimeters (L x W x H)
250 x 135 x 46
Certifications
| Adjustable Output Current Range (A) | Full-Power Current Range (A)(1) | Default Output Current (A) | Output Voltage Range (Vdc) | Max. Output Power (W) | Typical Efficiency (2) | Typical Power Factor | Model Number (3) (4) (5) |
|---|---|---|---|---|---|---|---|
| 0.125-1.7 | 1.25-1.7 | 1.7 | 200-544 | 680 | 95.5% | 0.99 | EUM-680S170MG |
| 0.18-2.4 | 1.8-2.4 | 2.1 | 141.5-378 | 680 | 94.5% | 0.99 | EUM-680S240MG |
| 0.26-3.5 | 2.6-3.5 | 3.5 | 97.1-262 | 680 | 95.0% | 0.99 | EUM-680S350MG |
| 0.42-5.6 | 4.2-5.6 | 5.6 | 60.7-163 | 680 | 94.5% | 0.99 | EUM-680S560MG |
| 0.63-8.4 | 6.3-8.4 | 8.4 | 40.4-108 | 680 | 95.0% | 0.99 | EUM-680S840MG |
| 1.26-15.0 | 12.6-15.0 | 15.0 | 22.6-54 | 680 | 95.5% | 0.99 | EUM-680S15AMG |
|
