- Ultra High Efficiency (Up to 93.5%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Dip-switch
- Non-dimming Control
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67
- SELV Output
- 5 Years Warranty
Life Time
85,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.70 x 2.66 x 1.56
Millimeters (L x W x H)
221 x 67.5 x 39.7
Certifications
| Adjustable Output Current Range |
Full-Power Current Range |
Default Output Current |
Input Voltage Range |
Output Voltage Range |
Max. Output Power |
Typical Efficiency |
Typical Power Factor |
Model Number | |
| 120Vac | 220Vac | ||||||||
| 500-1050mA | 700-1050mA | 700 mA | 90~305 Vac/ 127~250 Vdc |
95~286Vdc | 200W | 93.5% | 0.99 | 0.96 | EUP-200S105SV |
| 850-1500mA | 1050-1500mA | 1050 mA | 90~305 Vac/ 127~250 Vdc |
67~190Vdc | 200W | 93.5% | 0.99 | 0.96 | EUP-200S150SV |
| 1000-2100mA | 1400-2100mA | 1400 mA | 90~305 Vac/ 127~250 Vdc |
48~143Vdc | 200W | 93.0% | 0.99 | 0.96 | EUP-200S210SV |
| 1750-3500mA | 2450-3500mA | 2800 mA | 90~305 Vac/ 127~250 Vdc |
29 ~ 82Vdc | 200W | 93.0% | 0.99 | 0.96 | EUP-200S350SV |
| 3150-5600mA | 3850-5600mA | 4900 mA | 90~305 Vac/ 127~250 Vdc |
18 ~ 52Vdc | 200W | 92.0% | 0.99 | 0.96 | EUP-200S560SV |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
