• High Efficiency (Up to 90.5%)
  • Isolated 0-10V Dimmable (DVA models)
  • Non-Dimmable (SVA models)
  • Deep Dimming down to 0.1%
  • Constant Voltage PWM Output Frequency up to 1.5kHz
  • Dim-to-Off with Standby Power ≤ 0.5 W
  • Input Surge Protection: DM 4kV, CM 6kV
  • All-Around Protection: OCP, OVP, SCP, OTP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

89,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
7.08 x 2.66 x 1.44

Millimeters (L x W x H)
180 x 67.5 x 36.5

Certifications

Independent Gear Logo

Output Voltage Input Voltage Range Output Current Range Max. Output Power Typical Efficiency Typical Power Factor Model Number
12 V 90~305 Vac, 127~250 Vdc 0 ~ 12.5 A 150 W 90.0% 0.99 EUV-150S012DVA(SVA)
24 V 90~305 Vac, 127~250 Vdc 0 ~ 6.25 A 150 W 90.5% 0.99 EUV-150S024DVA(SVA)
File Name
LED Driver Installation Instructions (Updated March 2015)
Download
LED Driver Installation Guideline (Updated September 2018)
Download
