- Dimming Controls:
- DSP: 0-10V (compatible with Passive Dimmers)
- SSP: Non-Dimming
- Plastic Housing
- Class 2 and SELV Output
- 5 Year Warranty
Life Time
90,000 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
4.12 x 1.65 x 1.20
Millimeters (L x W x H)
104.5 x 42 x 30.5
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA |
90 ~ 305 Vac |
17 – 34 Vdc |
12 W |
LUC-012S035DSM(SSP) |
| 500 mA | 12 – 24 Vdc | LUC-012S050DSM(SSP) | ||
| 700 mA | 9 – 17 Vdc | LUC-012S070DSM(SSP) |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
