- High Efficiency up to 93.5%
- Constant Output Voltage
- No Load Power Consumption < 0.5 W
- Excellent Thermal Performance up to 50℃ Ambient Temperature
- Input Surge Protection: DM 2 kV
- All-Around Protection: OCP, OVP, OTP, SCP
- Class II
- SELV Output
- 5 Years Warranty
Life Time
120,000 Hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.34 × 2.30 × 1.48
Millimeters (L x W x H)
161 × 58.5 × 37.5
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Typical Efficiency | Model Number |
|---|---|---|---|---|---|
|
12V |
90 ~ 305 Vac/ 127~300 Vdc |
0 ~ 12.50 A |
150 W |
91.0% |
LUV-150S012SF |
|
24V |
90 ~ 305 Vac/ 127~300 Vdc |
0 ~ 6.25 A |
150 W |
92.0% |
LUV-150S024SF |
|
36V |
90 ~ 305 Vac/ 127~300 Vdc |
0 ~ 4.17 A |
150 W |
92.0% |
LUV-150S036SF |
|
48V |
90 ~ 305 Vac/ 127~300 Vdc |
0 ~ 3.13 A |
150 W |
93.0% |
LUV-150S048SF |
