• Non-Isolated Class I Driver
  • No Afterglow
  • Dim-to-Off with Standby Power ≤ 0.5W @ 230Vac
  • Ultra High Efficiency (Up to 97%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with NFC
  • 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
  • Adjustable Dimming Curve
  • INV Digital Dimming, UART Based Communication Protocol
  • Hold Time Adjustable
  • Fade Time Adjustable
  • Always-on Auxiliary Power: 12Vdc, 250mA
  • Minimum Dimming Level Supports 1%
  • Integrated Power Metering with High Accuracy up to ±1%
  • Low Inrush Current
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 10kV, CM 10kV
  • All-Around Protection: OPP, IOVP, IUVP, OVP, SCP, OTP
  • IP66/IP67 and UL Dry/Damp/Wet Location
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Years Warranty
Download Data Sheet
Order Here

Life Time

120,000 Hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
10.08 × 3.54 × 1.71

Millimeters (L x W x H)
256 × 90 × 43.5

Certifications

Independent Gear Logo

Adjustable
Output
Current
Range (mA)		 Full-Power
Current
Range
(mA)		 Default
Output
Current
(mA)		 Output
Voltage
Range
(Vdc)		 Max.
Output
Power
(W)		 Typical
Efficiency		 Typical Power Factor Model Number
220Vac 480Vac
13.6-2700 1360-2700 2700 150-500 680 97.0% 0.99 0.95 NFM-680S270MG
