- Non-Isolated Class I Driver
- No Afterglow
- Dim-to-Off with Standby Power ≤ 0.5W @ 230Vac
- Ultra High Efficiency (Up to 97%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
- Adjustable Dimming Curve
- INV Digital Dimming, UART Based Communication Protocol
- Hold Time Adjustable
- Fade Time Adjustable
- Always-on Auxiliary Power: 12Vdc, 250mA
- Minimum Dimming Level Supports 1%
- Integrated Power Metering with High Accuracy up to ±1%
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 10kV, CM 10kV
- All-Around Protection: OPP, IOVP, IUVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Years Warranty
Life Time
120,000 Hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
9.96 × 4.25 × 1.75
Millimeters (L x W x H)
253 × 108 × 44.5
Certifications
| Adjustable
Output Current Range (mA) |
Full-Power Current Range (mA) | Default
Output Current (mA) |
Output
Voltage Range (Vdc) |
Max. Output Power (W) | Typical
Efficiency |
Typical
Power Factor |
Model Number | |
| 220Vac | 480Vac | |||||||
| 17.6-3500 | 1760-3500 | 3500 | 150-500 | 880 | 97.0% | 0.99 | 0.95 | NFM-880S350MG |
