• Non-Isolated Class I Driver
  • No Afterglow
  • Dim-to-Off with Standby Power ≤ 0.5W @ 230Vac
  • Dimming Range: 0.1%-100%
  • 2*600W Independent Programmable Channels
  • Max Remote Distance Up to 300 Meters (Dimming and
    Output)
  • Ultra High Efficiency (Up to 97%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with NFC
  • DALI-2 and D4i Certified & DMX-RDM & 3-Timer-Modes
    Dimmable
  • Single-channel (1*DT6 or 1*DMX) Operating Mode
  • Multi-channel (2*DT6 or 2*DMX) Operating Mode
  • DALI-2/DMX-RDM Controls Up to 44 fps
  • Integrated Power Metering with High Accuracy up to ±1%
  • Thermal Sensing and Protection for LED Module
  • Low Inrush Current
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 10kV, CM 10kV
  • All-Around Protection: IOVP, IUVP, OVP, SCP, OTP, OPP
  • IP66
  • IK08 Enclosure
  • 5 Years Warranty

Life Time

100,000 Hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
19.69 × 5.98 × 3.15

Millimeters (L x W x H)
500 × 152 × 80

Certifications

Independent Gear Logo





Adjustable

Output

Current

Range (mA)

Full-Power Current Range (mA) Default

Output

Current (mA)

Output

Voltage Range (Vdc)

Max. Output Power (W) Typical

Efficiency

Typical

Power Factor

Model Number
220Vac 480Vac
1.2-2100 1200-2100 1200 176-500 1200 97.0% 0.99 0.95 NFS-1K2D210BC
