- Non-Isolated Class I Driver
- No Afterglow
- Dim-to-Off with Standby Power ≤ 0.5W @ 230Vac
- Dimming Range: 0.1%-100%
- 3*600W Independent Programmable Channels
- Max Remote Distance Up to 300 Meters (Dimming and Output)
- Ultra High Efficiency (Up to 97.5%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- DALI-2 and D4i Certified & DMX-RDM & 3-Timer-Modes Dimmable
- Single-channel (1*DT6 or 1*DMX) Operating Mode
- Multi-channel (Up to 3*DT6 or 3*DMX) Operating Mode
- DALI-2/DMX-RDM Controls up to 44 fps
- Hold Time Adjustable
- Fade Time Adjustable
- Integrated Power Metering with High Accuracy up to ±1%
- Thermal Sensing and Protection for LED Module
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 10kV, CM 10kV
- All-Around Protection: IOVP, IUVP, OVP, SCP, OTP, OPP
- IP66
- IK08 Enclosure
- 5 Years Warranty
Life Time
115,000 Hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
19.69 × 5.98 × 3.15
Millimeters (L x W x H)
500 × 152 × 80
Certifications
| Adjustable
Output Current Range (mA) |
Full-Power Current Range (mA) | Default
Output Current (mA) |
Output
Voltage Range (Vdc) |
Max. Output Power (W) | Typical
Efficiency |
Typical
Power Factor |
Model Number | |
| 220Vac | 480Vac | |||||||
| 1.2-2100 | 1200-2100 | 1200 | 176-500 | 1800 | 97.5% | 0.99 | 0.95 | NFS-1K8T210BC |
