- Panel Mount Connectors Facilitates Installation
- Rotary Switch+RJ12 Connector
- Hot-plugging Protection
- Parallel LED Protection
- Ultra High Efficiency (Up to 96%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC)with Programmability
- Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
- Adjustable Dimming Curve
- INV Digital Dimming, UART Based Communication Protocol
- Dim-to-Off with Standby Power ≤ 0.5W
- Minimum Dimming Level with 5% or 10% Selectable
- Hold Time Adjustable
- Fade Time Adjustable
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
- IP66 and UL Dry/Damp/Wet Location
- 5 Years Warranty
Life Time
110,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
16.73 × 4.25 × 1.91
Millimeters (L x W x H)
425 × 108 × 48.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
| 3.2-4 A | 3.3 A | 90-305Vac 127 – 300Vdc |
175~ 312Vdc | 1000W | SUM-1K0S400MGR |
| 6.72-8.4 A | 7.7 A | 84 ~ 149Vdc | SUM-1K0S840MGR | ||
| 18.5-20A | 18.5 A | 34 ~ 54Vdc | SUM-1K0S20AMGR |
|
