• Hot-plugging Protection
  • Parallel LED Protection
  • Ultra High Efficiency (Up to 96%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC)with Programmability
  • Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
  • Adjustable Dimming Curve
  • INV Digital Dimming, UART Based Communication Protocol
  • Dim-to-Off with Standby Power ≤ 0.5W
  • Minimum Dimming Level with 5% or 10% Selectable
  • Hold Time Adjustable
  • Fade Time Adjustable
  • Always-on Auxiliary Power: 12Vdc, 250mA
  • Low Inrush Current
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
  • IP66/IP67 and UL Dry/Damp/Wet Location
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Years Warranty
Download Data Sheet
Order Here

Life Time

110,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
15.31 × 3.54 × 1.91

Millimeters (L x W x H)
389 × 90 × 48.5

Certifications

Full-Power Current Range  Default Output Current  Input Voltage Range  Output Voltage Range  Max. Output Power  Model Number
3.2 – 4 A 3.3 A 90-305Vac
127 – 300Vdc		 175 – 312 Vdc 1000W SUM-1K0S400MT
6.72 – 8.4 A 7.7 A 84 – 149Vdc SUM-1K0S840MT
1.85 – 21 A 18.5 A 34 – 54Vdc SUM-1K0S21AMT
